Lancer ULTIMA 815LX Undercounter Laboratory Glassware Washer – Used and Refurbished
The Lancer ULTIMA 815LX Undercounter Glassware Washer is a high-performance laboratory washer and dryer designed for automated cleaning, rinsing, and drying of reusable laboratory glassware. Featuring a 140-liter (4.9 cu. ft.) stainless steel chamber, two independent washing levels, programmable wash cycles, direct-injection cleaning capabilities, and integrated forced-air drying, the 815LX provides a comprehensive glassware cleaning solution in a compact, space-saving design.
Manufactured by Getinge Lancer, the ULTIMA 815LX is designed for laboratories requiring consistent cleaning performance, flexible rack configurations, and reliable processing of glassware used in research, analytical testing, pharmaceutical development, and quality control.
Unlike basic laboratory glassware washers, the 815LX incorporates heated forced-air chamber drying to reduce residual moisture after washing and rinsing. An optional HEPA-filtered injector drying system is available for more effective drying of narrow-neck glassware when the appropriate accessories are installed.
The washer also features a 3.5-inch color touchscreen, a programmable PROLUX controller, and capacity for up to 40 wash programs, including four preset and 36 user-defined programs.
This Lancer ULTIMA 815LX is offered used and refurbished by American Instrument Exchange. Refurbished equipment is inspected and tested before shipment and includes a 90-day warranty, providing laboratories with a cost-effective alternative to purchasing a new glassware washer.
Key Features
-
Lancer ULTIMA 815LX undercounter laboratory glassware washer and dryer
-
140-liter (4.9 cu. ft.) stainless steel wash chamber
-
Compact 24-inch-wide design for laboratory casework
-
Two independent washing levels
-
Direct-injection washing with compatible racks and accessories
-
Integrated heated forced-air chamber drying
-
Optional HEPA-filtered injector drying for narrow-neck glassware
-
3.5-inch color touchscreen interface
-
PROLUX programmable microprocessor controller
-
40-program capacity: four preset and 36 user-defined programs
-
Maximum wash temperature of 95°C on applicable configurations
-
Maximum wash temperature of 85°C on 120V configurations
-
High-capacity 350 L/min (92 gal/min) recirculation pump
-
Automatic chemical dosing through peristaltic pumps
-
Compatible with purified-water rinsing
-
Approximately 12 liters (3.1 gallons) of water per fill
-
Stainless steel spray arms and wash chamber
-
Self-diagnostic functions and operating alarms
-
Counterbalanced fold-down door for convenient loading
-
Refurbished and tested by American Instrument Exchange
-
90-day warranty included
Overview
The Lancer ULTIMA 815LX is a programmable laboratory washer and dryer designed to automate the cleaning of reusable glassware and other compatible laboratory equipment.
Manual glassware washing can require substantial technician time, particularly when processing narrow-neck bottles, flasks, graduated cylinders, and vessels with difficult-to-reach interior surfaces.
The 815LX addresses these challenges through controlled wash programs, powerful water circulation, chemical dosing, and interchangeable rack configurations.
Its two-level washing system allows laboratories to accommodate different glassware types within a compact chamber. When equipped with appropriate injection racks, the washer can direct cleaning solution into the interiors of narrow-neck vessels.
The integrated forced-air drying system provides an additional processing stage after washing and rinsing, helping reduce residual moisture and improve turnaround time.
Common Applications
The Lancer ULTIMA 815LX is suitable for cleaning compatible laboratory bottles, beakers, Erlenmeyer flasks, graduated cylinders, test tubes, volumetric glassware, sample preparation containers, and reusable laboratory utensils.
Common applications include pharmaceutical research, biotechnology, analytical chemistry, microbiology, environmental testing, industrial quality control, and academic laboratory operations.
The types of glassware that can be processed depend on the installed racks, injection accessories, selected wash programs, and material compatibility.
Key Specifications
| Specification |
Details |
| Manufacturer |
Getinge Lancer |
| Series |
ULTIMA |
| Model |
815LX |
| Equipment Type |
Undercounter Laboratory Glassware Washer/Dryer |
| Installation |
Undercounter; Optional Base Cabinet Configuration |
| Chamber Capacity |
140 L (4.9 cu. ft.) |
| Exterior Dimensions |
24"W × 29.1"D × 33.5"H |
| Interior Dimensions |
21.1"W × 20.5"D × 19.6"H |
| Chamber Material |
304L Stainless Steel |
| Spray Arms |
316L Stainless Steel |
| Washing Levels |
2 |
| Controller |
PROLUX Programmable Controller |
| Display |
3.5" Color Touchscreen |
| Wash Programs |
4 Preset + 36 User-Defined |
| Maximum Wash Temperature |
95°C on Applicable Configurations |
| Maximum Temperature, 120V |
85°C |
| Drying System |
Heated Forced-Air Chamber Drying |
| Optional Drying |
HEPA-Filtered Injector Drying |
| Drying Heater |
2.4 kW |
| Wash Water Heating |
6 kW on Applicable Configurations |
| Recirculation Pump |
350 L/min (92 gal/min) |
| Water Consumption |
Approximately 12 L (3.1 gal) per Fill |
| Water Supply Pressure |
29–87 psi (200–600 kPa) |
| Water Supply |
Cold and Purified/DI Water Connections |
| Chemical Dosing |
Automatic Peristaltic Pumps |
| Noise Level |
Approximately 60 dB(A) or Less |
| Net Weight |
Approximately 187 lb (85 kg) |
| Electrical Options |
120V or 208V, Configuration-Dependent |
| Electrical Phase |
Single-Phase or Three-Phase, Depending on Version |
| Racks and Inserts |
Verify Included Accessories |
| Condition |
Used / Refurbished |
| Warranty |
90 Days |
Specifications are based on Getinge Lancer ULTIMA 815LX technical documentation. The exact electrical configuration, included racks, drying accessories, and optional equipment should be verified on the individual refurbished washer.
Ideal Laboratory Types
The Lancer ULTIMA 815LX is well suited to pharmaceutical research laboratories, biotechnology facilities, analytical chemistry departments, molecular biology laboratories, environmental testing facilities, academic research institutions, and industrial quality-control laboratories.
Its compact design is particularly useful for facilities requiring automated glassware cleaning and drying without dedicating substantial floor space to a larger freestanding washer.
Integrated Forced-Air Drying
One of the principal advantages of the ULTIMA 815LX is its integrated forced-air drying system.
After the washing and rinsing stages, heated air circulates through the chamber to help remove residual moisture from compatible glassware.
The manufacturer specifies a 2.4 kW heating and blower system for chamber drying.
This feature can reduce the need for separate drying equipment and help laboratories return cleaned glassware to service more quickly.
Drying performance depends on the selected program, glassware geometry, rack arrangement, and operating conditions.
Optional HEPA-Filtered Injector Drying
The 815LX was also offered with an optional HEPA-filtered injector drying system.
When installed with compatible injection racks, this system can direct filtered heated air into narrow-neck bottles and flasks.
This is particularly useful for vessels that may retain moisture after conventional chamber drying.
The HEPA-filtered injector drying system is an optional feature and should not be assumed included with every 815LX.
Customers should confirm whether this accessory is installed on the refurbished unit before purchase.
Two-Level Direct-Injection Washing
The ULTIMA 815LX supports washing on two independent levels.
With compatible injection racks, cleaning solution can be delivered directly into laboratory bottles, flasks, and other narrow-neck vessels.
This targeted washing action is useful for glassware that may be difficult to clean using external spray coverage alone.
The washer also incorporates stainless steel spray arms for cleaning accessible exterior and interior surfaces.
Interchangeable racks allow the chamber to be configured for different laboratory applications.
PROLUX Touchscreen Controller
The Lancer 815LX ULTIMA features a 3.5-inch color touchscreen interface and PROLUX programmable controller.
The controller supports four preset wash programs and up to 36 user-defined programs.
Operators can configure parameters for prewashing, detergent washing, rinsing, purified-water rinsing, and drying.
The system also includes password-protected programming levels, operating alarms, and self-diagnostic functions.
These capabilities help laboratories establish repeatable cleaning procedures appropriate for their applications.
High-Temperature Washing and Rinsing
The 815LX supports elevated-temperature washing and rinsing.
On applicable electrical configurations, the manufacturer specifies a maximum wash temperature of 95°C.
The 120V version is limited to approximately 85°C.
Elevated-temperature processing can improve removal of certain residues and support appropriately developed cleaning procedures.
However, maximum temperature capability does not automatically establish that a cleaning or disinfection cycle has been validated for a particular laboratory application.
Automatic Detergent and Acid Dosing
The ULTIMA 815LX incorporates automatic peristaltic dosing pumps for compatible cleaning and neutralizing agents.
Automated chemical dosing helps deliver repeatable amounts of detergent and acid during selected program stages.
This can improve cleaning consistency and reduce the need for manual chemical measurement.
Appropriate chemical selection and concentration depend on the glassware materials, residue types, water quality, and cleaning requirements.
The dosing pumps, tubing, and chemical connections should be inspected before operation.
Water Circulation and Cleaning Performance
The 815LX uses a high-capacity recirculation pump rated at approximately 350 liters per minute, equivalent to 92 gallons per minute.
This system delivers wash water through the chamber spray assemblies and compatible injection racks.
The manufacturer specifies approximately 12 liters of fresh water per fill.
The total water consumed during a complete cleaning program depends on the number of washing and rinsing stages selected.
Proper loading, detergent selection, water quality, and rack configuration are important factors in achieving consistent cleaning results.
Purified-Water Rinsing
The Lancer 815LX supports purified or deionized-water rinse stages when connected to an appropriate water supply.
Purified-water rinsing can help reduce mineral deposits and other residues on cleaned laboratory glassware.
This is particularly useful in analytical chemistry, pharmaceutical research, and other applications where residual contamination may affect downstream results.
The laboratory's water supply must meet the manufacturer's pressure, flow, and connection requirements.
Stainless Steel Construction
The ULTIMA 815LX features a 304L stainless steel chamber and door, with 316L stainless steel spray arms.
These materials provide durability and resistance to many cleaning chemicals used in laboratory washing applications.
The chamber and door are insulated to help reduce heat loss and operating noise.
The counterbalanced fold-down door also provides a convenient loading platform for the lower wash level.
Rack and Glassware Compatibility
The Lancer ULTIMA series supports a range of interchangeable washing racks and baskets.
Available configurations include general-purpose baskets, injection racks, and specialized holders for different glassware types.
The appropriate rack system is particularly important for narrow-neck flasks, volumetric glassware, and other vessels requiring internal spray coverage.
Customers should verify the exact racks, baskets, injector nozzles, and accessories included with the refurbished washer.
Lancer 815LX vs. 810LX
The Lancer ULTIMA 815LX and 810LX share a similar compact footprint, chamber capacity, and two-level washing configuration.
The principal distinction is the 815LX's integrated forced-air drying capability.
The 815LX also supports optional HEPA-filtered injector drying for compatible narrow-neck glassware.
For laboratories requiring washing and rinsing only, the 810LX may be sufficient.
For facilities seeking a more complete washing and drying workflow, the 815LX offers additional flexibility.
Refurbishment and Testing by American Instrument Exchange
American Instrument Exchange inspects, tests, and reconditions used laboratory glassware washers before shipment.
For the Lancer ULTIMA 815LX, relevant testing includes operating programmed wash cycles, evaluating water circulation and drainage, verifying heating performance, inspecting the touchscreen controller, and checking the door seal and safety interlocks.
The forced-air drying system, blower, dosing pumps, spray assemblies, water connections, and available rack accessories should also be evaluated.
Customers requiring documented temperature testing, confirmation of specific wash programs, or verification of optional HEPA-filtered injector drying should discuss these requirements with AIE before purchase.
The refurbished Lancer ULTIMA 815LX includes a 90-day warranty.
Shipping and Installation
The Lancer ULTIMA 815LX measures approximately 24 inches wide, 29.1 inches deep, and 33.5 inches high, with a manufacturer-listed weight of approximately 187 pounds.
The washer is designed for installation beneath compatible laboratory countertops and may also be installed with an appropriate optional base cabinet.
Installation requires suitable electrical service, water supply connections, and drainage.
Electrical requirements vary significantly by configuration. Manufacturer documentation identifies 120V single-phase and 208V single- or three-phase versions.
Customers should confirm the individual washer's electrical rating before installation.
The laboratory should also provide sufficient clearance for the fold-down door, loading operations, plumbing, and service access.
Related Equipment
Laboratories using the Lancer ULTIMA 815LX may also require other laboratory glassware washers, laboratory autoclaves and sterilizers, water purification systems, laboratory ovens, and laboratory glassware.
American Instrument Exchange supplies used and refurbished glassware washers and related laboratory equipment for biotechnology, pharmaceutical, academic, and industrial laboratories.
Lancer ULTIMA 815LX FAQs
What is the Lancer ULTIMA 815LX used for?
The 815LX is an automated laboratory glassware washer and dryer designed to clean, rinse, and dry compatible reusable laboratory glassware.
Does the Lancer 815LX include a drying system?
Yes. The ULTIMA 815LX includes heated forced-air chamber drying as a standard feature.
Does the 815LX have HEPA-filtered drying?
HEPA-filtered injector drying was offered as an optional feature. Its presence should be confirmed on the individual unit.
What is the chamber capacity?
The 815LX has a 140-liter chamber, equivalent to approximately 4.9 cubic feet.
How many wash programs does the 815LX support?
The ULTIMA version supports four preset programs and up to 36 user-defined programs.
What is the maximum wash temperature?
Applicable configurations reach 95°C, while the 120V version is limited to approximately 85°C.
Can the 815LX wash narrow-neck laboratory flasks?
Yes, when equipped with compatible direct-injection racks and accessories.
Does the washer support deionized-water rinsing?
Yes. The 815LX supports purified-water rinse stages when connected to an appropriate water supply.
What is the difference between the 815LX and 810LX?
The 815LX adds integrated forced-air drying and offers optional HEPA-filtered injector drying.
Are washing racks included?
The exact racks, baskets, injectors, and other accessories included with the refurbished unit should be confirmed before purchase.
Does the refurbished Lancer 815LX include a warranty?
Yes. American Instrument Exchange includes a 90-day warranty on refurbished equipment.
