Memmert Universal Oven UN30
The Memmert Universal Oven UN30 is a universally applicable lab oven and is Memmert’s classic appliance for temperature control in science, research and material tests in the industry. The technologically perfected masterpiece made of high-quality, hygienic, easy-to-clean stainless steel leaves nothing to be desired in terms of ventilation and control technology, overtemperature protection and precisely tuned heating technology.
Memmert Universal Oven UN30 features
Temp range: min. 5°C above ambient up to +300°C
1.1 cubic foot chamber
Gravity convection
Stainless steel construction
90-day warranty
ControlCOCKPIT: adaptive multifunctional digital PID-microprocessor controller with high-definition TFT-color display. Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days. Adjustable Parameters: temperature (Celsius or Fahrenheit), air flap position, program time, time zones, daylight savings time. Function SetpointWAIT: the process time does not start until the set temperature is reached. Language Setting: German, English, Spanish, and French. Calibration: three freely selectable temperature values.
Memmert Universal Oven UN30 specifications
Volume approx.
1.1 Cu Ft (32 L)
Temperature range
+5°C above ambient temperature to +300°C
Setting temperature range
+20° to +300°C
Setting accuracy °C
up to 99.9: 0.1 / from 100: 0.5
Contoller
SingleDISPLAY: TFT color touchscreen, manage data, save log files, monitor up to 32 devices online, automatic alarms emailed
Interfaces
Ethernet
Housing
Textured stainless steel, rear zinc-plated steel, TFT color display with touchscreen, fully insulated stainless steel door
Interior
Stainless steel (ASTM 304) with all-round deep-drawn ribs to integrate the large-area heating with ceramic-metal sheath
Fresh air
Admixture of pre-heated fresh air by electronically adjustable air flap
Chamber Dimensions (W x H x D)
15.7 x 12.6 x 9.8 inches (400 x 320 x 250 mm)
Maximum number of grids/shelves
3 (1 included)
Maximum loading per grid/shelf
44 lbs (20 kg)
Maximum loading of chamber
132 lbs (60 kg)
Maximum loading per slide-in drip tray
3.3 lbs (1.5 kg)
Maximum loading per bottom drip tray
3.3 lbs (1.5 kg)
Exterior Dimensions (W x H x D)
23 x 27.7 x 17.1 inches (585 x 704 x 434 mm)
Standard works calibration certificate (measuring point chamber center)
°C +160
Electrical
115 V, 50/60 Hz, 1600 Watts
